ProMA Series
Outdoor Weatherproof Access Control Terminal On-board Web server function High strength Aluminum alloy casting casing with IK07 User: 50,000 User Fingerprint: 10,000 Face: 30,000 Cards: 50,000 Transactions: 500,000 IP66 (water dust proof) ZKFace v3.9 ZKFinger v10.0 Wiegand: Input Output RS485: Input Output ZK Bio CV Security Software License
ProMA is a standalone outdoor biometric multi-access control station built from a super-strong aluminum alloy with a die-cast housing. The ProMA series enhances the protection level to reach the water and dust resistance standard (IP66) and anti-vandalism standard (IK07). There are three models in the ProMA series. which are equipped with different authentication combinations. facial recognition, fingerprint recognition, and multi-technology RFID recognition. labeled ProMA-QR (face + QR code + RFID). ProMA-RF (face+RFID). ProMA (face+fingerprint+RFID). In addition, the the latest contactless palm recognition technology is also available in this terminal as an option.
Specifications
| Model | ProMA | ||
| Capacity | Fingerprint: 10,000 (Only ProMA) Face: 30,000 (Optional: 50,000 only ProMA-QR ProMA-RF) Palm: 5,000 (Optional) Cards: 50,000 (Optional: 100,000 only ProMA-QR ProMA-RF) Transactions: 500,000 | ||
| Hardware | 1.0GHz Quad Core CPU Memory 1G RAM / 8G Flash Z-ID + Fingerprint Sensor (Available on ProMA only) QR code Sensor (Available on ProMA-QR only) 2.0 Inches color TFT Monitor Hi-Fi Voice Indicator Tamper Switch Alar | ||
| Optional Functions | Palm recognition PoE IEEE 802.3af/at (external) HID Proxy/iClass/multi-tech Card module Scramble QR code recognition (Supports: PDF417, Data Matrix, MicroPDF417, Aztec, available on ProMA-QR only) |
||
| Communication | 1* TCP/IP (TLS1.2, AES-256 end to end secured communication channel) 1* Wiegand Input/Output 1*Standard RS485/OSDP V2.1.7 over RS485 (AES-128, OSDP V2.1.7 Secured Channel) | ||
| Communication | TCP/IP, Wi-Fi, Bluetooth, 3G/4G | ||
| CPU | ZKTeco Customized Computer Vision eight-core processor | ||
